The ZigBee 5.8G/24G mmWave Radar (Wenzhi) is a smart human presence sensor utilizing advanced millimeter-wave radar technology to detect movement, micro-motion, and even sleeping individuals with high precision. Designed for smart home integration via ZigBee, it supports multiple installation methods and includes built-in light sensing and a 16A relay for seamless automation.

Color - ZigBee 5.8G Ceiling

ZigBee 5.8G Ceiling ZigBee 24G Ceiling ZigBee 5.8G Circular ZigBee 24G Circular

Product variants

Quantity

Buy elsewhere

add_shopping_cart

Order Today

local_shipping

- - -

Order Ready

redeem

- - -

Delivered

ZigBee 5.8G/24G MmWave Radar (Wenzhi)

$39.99

$39.99 ~~$60.00~~

SAVE 33% Sold out

check_box

Specifications

Brand Name: Wenzhi
Certification: CE
Certification: RoHS
Detection Range: 10m
Origin: Mainland China
Detection Angle: 110*110°
Highly concerned Chemicals: None
Model Number: WZ75
Network: ZigBee
input: 85-240VAC.
Working temperature: -10℃~+50℃
Sensitivity: 1-9(default 7)
5.8G Beam Angle:120X120
24G Beam Angle:110X110°
5.8G Sensing distance: 0-11m(default 6m)
24G Sensing distance: 2.5-10m(default 7m)
5.8G Sensing radius: 2.5-3m(Presence),4～5.5m(motion).
24G Sensing radius: 2-3m(Presence),4～4.5m(motion).
Illuminance Sensor: 0～500 Lux（The approximate brightness of the environment in which the sensor is located）.
Departure Delay: 0.5s～25 min；It is recommended to set it to no less than 15S. Otherwise, detection may be missed.
Transmitting Power: 3～5 dBm(5.8G), 10dBm(24G).
Working Humidity: 5～90% RH(No Condensation).
Protection Level: IP20.
Relay Load: Resistive load≤3000W LED≤300W.
circular Size: Φ105mm*28mm/Φ4.13inch*1.1inch
Ceiling Mount Size: Φ75mm*61mm/Φ2.95inch*2.4inch

PACKAGE LIST:
Human presence sensor*1
User manual*1
Expansion screws*2(circular)
Double-sided tape*1(circular)

View full details

ZigBee 5.8G/24G MmWave Radar (Wenzhi) - SyncYourHome, multiple sensor parameters can be set in the app

Adjustable Sensor Parameters via App

Easily configure sensor behavior to match your environment through the Tuya Smart app. Users can fine-tune detection sensitivity, range, delay times, and more—ensuring precise performance for bedrooms, offices, hallways, or any other space. The intuitive interface allows real-time updates and customization without the need for complex setup or firmware changes.

ZigBee 5.8G/24G MmWave Radar (Wenzhi) - SyncYourHome, more accuracy

Multiple Relay (Breaker) Control Modes

The device offers three versatile relay modes: Standard (cloud-controlled), Local (automatic based on presence), and Disabled (sensor-only). These options let users choose between app-based manual control, smart automation, or power-saving configurations. Ideal for integrating directly with lighting or appliances, the flexible relay settings reduce the need for separate smart switches.

ZigBee 5.8G/24G MmWave Radar (Wenzhi) - SyncYourHome, Rich and diverse parameter settings

Rich and Versatile Parameter Options

With a wide range of both common and control parameter settings, the sensor can be tailored to suit virtually any scenario. Whether you're avoiding false triggers, adjusting for ambient interference, or fine-tuning response delays, the system offers granular controls. This level of customization ensures high reliability in diverse applications—from residential automation to commercial deployments.

ZigBee 5.8G/24G MmWave Radar (Wenzhi) - SyncYourHome, illumination detection function

Built-in Illuminance Detection for Smarter Automation

The integrated light sensor measures ambient brightness and enables dynamic lighting control based on real-world conditions. When paired with the app’s smart scene linkage, lights can automatically turn on or off depending on both human presence and surrounding light levels. Users can set specific brightness thresholds (0–420 Lux) to automate behavior precisely as desired.
